New
FIRE FOAM
高防火性密封泡沫胶
描述
FIRE FOAM，EI240防火认证的高性能泡沫密封剂
其均匀的分子结构、尺寸稳定性和机械性能使其成为所有防火要求高的情况下保温、密封和填充的理想材料。
文件
-
技术数据表
-
符合性声明（DOC）
-
Fire test report
-
证书 被 EMICODE
FIRE FOAM
| CODE | content
[ml]
|
yield
[l]
|
content
[US fl oz]
|
yield
[US gal]
|
description | version | pcs. |
|---|---|---|---|---|---|---|---|
| FIREFOAM | 750 | 42 | 25.36 | 11.1 | ALUMINIUM CARTRIDGE | GUN | 12 |
技术数据
| 属性 | 标准 | 数值经过测试 | USC 转换 |
|---|---|---|---|
| Post expansion | EN 17333-2 | 90 / 120 % | - |
| Yield | - | 42 dm3 | 0 ft3 |
| Film formation time 23°C/50 %RH (1 ) | - | 10 / minutes | - |
| Cutting time 23 °C / 50% RH (1 ) | - | 40 / minutes | - |
| Time required for complete hardening 23 °C / 50% RH (1 ) | - | 1440 minutes | - |
| Application temperature (ambient, cartridge and support) (2 ) | - | 10 / 30 °C | 50 / 86 °F |
| Dimensional stability | EN 1107-2 | ≤ 3 % | - |
| Reaction to fire | EN 13501-1 | class B-s1,d0 | - |
| Reaction to fire | DIN 4102-1 | class B1 | - |
| Fire resistance rating on concrete joint* (3 ) | en 1366-4 | EI240 | - |
| Fire resistance rating on CLT joint* (3 ) | en 1366-4 | EI90 | - |
| Emicode | procedura di prova GEV | EC1 plus | - |
| French VOC classification | ISO 16000 | A+ | - |
| Transport temperature | - | -20 / 30 °C | -4 / 86 °F |
| Storage temperature | - | 5 / 30 °C | 41 / 86 °F |
1. The data expressed may vary depending on the thickness of the product applied and the specific installation conditions: temperature, humidity, ventilation, absorbency of the substrate.
2.
3. For full details and tested configurations, please refer to the manual or contact our technical department.
