高耐火硅酮密封胶

FIRE SEALING SILICONE

FIRE SEALING SILICONE是一种高度耐火的硅酮密封胶(B-s1,d0级),非常适合在防火规范要求的情况下密封防火墙和门的线性接缝。

FIRE SEALING SILICONE,具有B-s1、d0级高耐火性的硅酮密封胶

FIRE SEALING SILICONE是一种经过测试的硅酮密封剂,旨在提供最大限度的保护,防止火焰、烟雾或气体通过。在防火规范要求的情况下密封防火墙和门的线性接缝的理想选择。根据EN 15651-1,它被分类为室内和室外非结构用途,也可用于立面和气候寒冷的地区。高粘附力和高抗紫外线能力。

文件

技术数据表
Test Report
Fire test report

FIRE SEALING SILICONE

CODE content
[ml]
contenuto
[US fl oz]
colour version pcs.
FIRESILGRE310 310 10.48 GREY PLASTIC CARTRIDGE 24

Technical Data
EN 15651-1
EN 13501-1 B-s1,d0
EN 13501-5 EI240

属性 标准 数值经过测试 USC 转换
Composition - silicone -
Classification (1) EN 15651-1 F-EXT/INT-CC -
Density ISO 1183-1 1,482 g/mL 237.65 oz/gal
Yield for 10x10 mm joint - 3,1 m 10.17 ft
Surface cross-linking time 23 °C (2) - 80 minutes -
Hardening speed 20 °C / 50 %RH - ca. 2 mm/24h -
Shore A hardness DIN 53505 ca. 30 -
Elongation at failure DIN 53504 460 % -
Tensile strength DIN 53504 0,72 N/mm² 104 lbf/in²
Compressive modulus 100% DIN 53504 0,38 N/mm² 55 lbf/in²
Reaction to fire EN 13501-1 class B-s1,d0 -
Fire resistance (3) EN 13501-2 EI240 -
Acid resistance - excellent -
Bases resistance - excellent -
VOC content - 4.3 % - 64 g/L -
French VOC classification ISO 16000 A+ -
Emicode procedura di prova GEV EC1 -
Storage temperature (4) - 5 / 35 °C 41 / 95 °F
1.
2. The data expressed may vary depending on the thickness of the product applied and the specific installation conditions: temperature, humidity, ventilation, absorbency of the substrate.
3. Valid value for tested configurations
4.
